Introduction
Product Overview
In 2024, digital transformation continues to advance. The NDiS B362 Visual Edge Computer, powered by Intel® Core™ Ultra 7 and 5 processors with an integrated NPU for AI inference, offers optimized workloads across CPU, GPU, and NPU, resulting in up to 22.4 TOPS of AI computing power while maintaining energy efficiency.
Dual HDMI 2.0 ports deliver exceptional visuals, and a variety of I/O interfaces support a wide range of AI applications. Designed to operate in extreme temperatures from 0°C to 60°C, the NDiS B362 is ideal for semi-outdoor applications such as self-service kiosks, smart beverage stations, smart recycling machines, and intelligent parking systems.
Specifications
-
CPUMeteor Lake 165U, 12-core/4.9GHz,Intel® Core™ Ultra 7
Meteor Lake 155U, 12-core/4.8GHz,Intel® Core™ Ultra 7
Meteor Lake 135U, 12-core/4.4GHz,Intel® Core™ Ultra 5
Meteor Lake 125U, 12-core/4.3GHz,Intel Core Ultra 5
Only 165U/135U support Intel® AMT -
Memory2 x DDR5 5600 262-pin SO-DIMM, non-ECC, unbuffered, up to 96GB
-
GraphicsIntel® Graphics
-
Storage1 x M.2 Key M 2280 for optional SSD (PCIe 3.0 x4, SATA 3.0)
-
Display2 x HDMI 2.0, up to 4096 x 2160@60Hz
-
Audio1 x Line out
-
LAN1 x 2.5GbE RJ45 Port, Intel® i2261 x GbE RJ45 Port, Intel® I219
-
COM2 x COM Port, supports RS-232/RS422/RS485
-
USB1 x USB 3.2 Gen 1x1, Type-A3 x USB 2.0
-
GPIO1 x 10-pin header for GPIO, 4 x DI, 4 x DO
-
M.21 x M.2 Key E 2230 for optional Wi-Fi module
1 x M.2 Key B 3052/2242 for optional 5G/LTE module
(PCIe 3.0 x1, USB 3.0, USB 2.0) -
Power+12V, 96W AC/DC power adapter in carton
-
DimensionsDimension: 200mm (W) x 140mm (D) x 37mm (H) w/o bracket
-
WeightNet weight: 1.26 kg/Unit
-
Operating SystemWindows 11, 64bitWindows 10, 64bitLinux
-
EnvironmentAmbient with air flow: 0°C ~ 55°C (Core Ultra 7-165U & 155U)
Ambient with air flow: 0°C ~ 60°C (Core Ultra 5-135U & 125U) -
CertificationsCE Approval (EN50035 + EN50032)
FCC Class A (Part 15B)
LVD (EN62368-1) -
TPMTPM 2.0
